BOTTOM BRACKET SRAM DUB PF 92 MTB Wide / shell 41x92mm
BRAKES Shimano XT M8120 4 Piston Disc; Shimano SM-RT76 / 6 Bolt / 203/F and 180/R
CASSETTE SRAM XG1275 / 10-52 T
CHAIN SRAM CN GX Eagle
CRANKSET SRAM GX Eagle DUB; 55mm CL / 32T
EXTRAS SRAM AXS Powerpack; Syncros Fork Fender
FORK FOX 36 Float Performance Elite Air FIT4; 3-Modes with low Speed adj. / Kabolt 15x110mm axle; 44mm offset / tapered steerer / Reb. Adj. / Lockout; 160mm travel
FRAME Genius Carbon HMF Mainframe with Alloy 6061 Swingarm; Integrated Suspension Technology; Virtual 4 Link kinematic / Adjustable head angle; Syncros Cable Integration System; BB92 / UDH Interface / 12x148mm with 55mm Chainline
FRAME MATERIAL Carbon
FRONT TRAVEL 160mm
FRONT TYRE Maxxis Dissector / 2.6 / 60TPI Foldable; Tubeless Ready / EXO 3C maxx Terra
HANDLEBAR Syncros Hixon iC Carbon; Size S & M 15mm rise / Size L & XL 25mm rise; back sweep 8degrees / 780mm; Syncros Endurance lock-on grips
HEADSET Syncros - Acros Angle adjust & Cable Routing HS System; +-0.6degrees head angle adjustment; ZS56/28.6 - ZS56/40 MTB
REAR DERAILLEUR SRAM GX Eagle AXS 12 Speed; Wireless Electronic Shift System
REAR TRAVEL 150-100-Lockout
REAR TYRE Maxxis Dissector / 2.6 / 60TPI Foldable; Tubeless Ready / EXO 3C maxxTerra
REMOTE SYSTEM SCOTT TwinLoc 2 Technology; Suspension & Dropper Remote; 3 Suspension modes
SADDLE Syncros Tofino 1.5 Regular; Titanium rails
SEATPOST Syncros Duncan Dropper Post 1.5; 31.6mm / S size 140mm / M size 160mm; L size 170mm / XL size 200mm
SHIFTERS SRAM GX Eagle AXS Rocker Controller
SHOCK FOX NUDE 5T EVOL Trunnion; SCOTT custom w. travel / geo adj.; 3 modes: Lockout-Traction Control-Descend; Custom large Air volume / DPS / Reb. Adj.; Travel 150-100-Lockout / T185X55mm
WHEELSET Syncros Revelstoke 1.5 6 Bolt; F: 15x110mm; R: 12x148mm; 30mm Tubeless ready rim 28H / XD Driver; Syncros Axle w/ Removable Lever; with 6mm Allen; T30 and T25 Tools
WHEEL SIZE 29
